The difference between today's genuine shell and imitation shell
Note: The product does not contain power!9V power supply.
- Maximum real -time sampling rate: 1MSPS
- Accuracy: 12bit
- Sampling buffer depth: 1024 bytes
- Introduction frequency bandwidth: 0-2KHz
- Vertical sensitivity: 5MV/DIV–20V/DIV (progressive by 1-2-5)
- Vertical displacement can be adjusted, with instructions
- Input impedance: 1MΩ
- Maximum input voltage: 50VPP (1: 1 probe), 400VPP (10: 1 probe)
- The coupling method includes DC/AC/GND
- Base range: 10μs/Div–50S/DIV (progressive by 1-2-5)
- It has automatic, conventional and single triggers, which is convenient to capture instantaneous waveforms
- Available rising or decreased edges triggers
- The position of the level can be adjusted, with instructions
- Observe the previous waveform (negative delay)
- You can freeze the waveform display at any time (HOLD function)
- Comes with 1kHz /3.3V square wave test signal source
- Banding parameter number display, the displayed parameters are:frequency, Periodic, pulse width, duty occupation ratio, maximum value, minimumValue, average value, Peak value, valid value
- Save/call the waveform, shut down the waveform and not disappear
